Cirris® Easy-Touch™ Pro User Manual
The yellow lightning bolt symbols on the tester inform operators that high voltage is involved with the scanner modules
and that there is risk of electric shock. The yellow exclamation mark means to use caution and also to see the manual for
more information.
When performing a high voltage test, the Easy-Touch Pro tester limits the Total Current to 2.5 milliamps and the applied
charge to 45 micro coulombs. These electrical levels are considered safe for adults; however, some people could be ad-
versely aected even at these levels. To avoid risk, ensure that you do not touch the cable during the hipot test. Using a DC
voltage for high voltage testing also provides an added level of operator safety. See the Cirris website for more hipot safety
information.
See manual for more information
The symbols with a white exclamation mark on the back of the tester, inform operators that more information about the
Digital I/O, Auxiliary HV input, and Auxiliary Input Supply Connections can be found in the Easy-Wire online help system.
The Digital I/O Connector allows the tester to respond to inputs and create outputs without the use of a PLC. Easy-Wire
software version 2012.2 or higher has Digital I/O capability. See the Easy-Wire help system for more information.
4.6 Conditions for Operation
Your Easy-Touch Pro Tester is intended to be used indoors at a temperature of 50 to 104 degrees Fahrenheit (10 to 40 de-
grees Celsius).
Best performance can be obtained at a relative humidity of less than 70%. Insulation Resistance Measurements will degrade
at over 70% relative humidity.
The unit can be mounted in a ventilated compartment. Be sure not to block the vents on the sides and back of the tester.
Never apply live voltages to the test points or probe input of your Cirris tester. Power supplies and other accessories not ap-
proved by Cirris may cause damage or present a hazard. If you use a Cirris product in a manner not specied in this manual
and the accompanying help system, the protection provided by the product may be impaired.
4.7 Helpful Links
● Request a PDF of this document and Performance Verication Manuals:
http://www.cirris.com/support/request_manual.html
● Request an RMA for repair or calibration:
http://www.cirris.com/support/request-rma.html
● Request a new Easy-Touch Pro feature:
http://www.cirris.com/support/featurereq.html
● Report a bug or undesired behavior relating to the tester or the software:
http://www.cirris.com/support/bugreport.html
