Cirrus DESIGN SR20 - Page 99

Cirrus Design Section 3A
SR20 Abnormal Procedures
P/N 11934-004 3A-7
Figure 3A-1
Circuit Breaker Panel
EVS
CAMERA
CABIN
FAN
STARTER
AVIONICS
FAN 1
RECOG
LIGHTS
NAV
LIGHTS
STROBE
LIGHTS
PITOT
HEAT
FLAPS
AVIONICS
FAN 2
GPS NAV
GIA 2
COM 2
AHRS 2
FUEL
PUMP
PFD #2
MFD #1
12V DC
OUTLET
ALT1
CABIN AIR
CONTROL
SR20_FM03A_3006
BAT 2
GPS NAV
GIA 1
COM 1
ADC 1
STDBY
ATTD #1
PFD #1
PITCH
TRIM
ROLL
TRIM
ENGINE
INSTR
ALT2
STALL
WARNING
ESSENTIAL
POWER
AHRS 1
DME / ADF
AUDIO
PANEL
WEATHER
TRAFFIC
AP SERVOS
FUEL QTY
MFD #2
STDBY
ATTD #2
CABIN
LIGHTS
KEYPADS
/ AP CTRL
XPONDER
AVIONICS
Original Issue
