CISA eSIGNO - Lock Visual Signals

ESIGNO_SYSTEM_USER_MANUAL_101.DOCX 27/71
L
LL
LOCK
OCKOCK
OCK
V
VV
VISUAL
ISUAL ISUAL
ISUAL S
SS
SIGNALS
IGNALSIGNALS
IGNALS
A
AA
ACCESS
CCESS CCESS
CCESS T
TT
TARGETS
ARGETSARGETS
ARGETS
1 GREEN
Door already in office or danger status
2 GREEN
Function executed successfully
(block, synchronization, office on, reset, etc.)
5 GREEN
Opening enabled
10 GREEN 10x
Lock not initialized
1 RED
Reading error. If repeated every 3 seconds: Privacy active
Privacy activePrivacy active
Privacy active
(also on Cisa logo near the privacy button on internal side)
3 RED
Card not valid (expired, invalidated by a new one, etc.)
6 RED 6x
Device not synchronized
3 RED + 1
GREEN
Card temporarily not valid
(blocked, out of the working hours, guest in privacy)
3 GREEN + 1RED +
2 GREEN
Initialization OK
1 RED&GREEN
Operation in progress (followed by 2 green or 2 red
depending on the result)
3 RED&GREEN
Low battery (Staff cards only)
4 RED&GREEN
Function of card in sequence executed successfully
10 RED&GREEN 10x
Delayed close (Staff cards only, if DPR is enabled)
12 RED&GREEN 12x
End battery
20 RED&GREEN 20x
Tampering: DPR circuit disconnected (Staff cards only)
1 BLUE
Communication with HHI via mouse in progress
