IP Communication Solution for Group Applications Configuration Example
Configure
4
OL-6574-01
Configure
In this section, you are presented with the information to configure the features described in this
document.
Note To find additional information on the commands used in this document, use the Cisco IOS Command
Lookup tool. You must have an account on Cisco.com. If you do not have an account or have forgotten
your username or password, click Cancel at the login dialog box and follow the instructions that appear.
Configuration Tips
• The gigabit port on the router does not provide inline power.
• Routing should be enabled and assumed to be configured.
• The external flash card on the integrated services routers holds the router image, VLAN database,
graphical user interface (GUI) files for Cisco CME and Cisco Unity Express. It should not be
removed during the normal operation of the router.
• The LMR integration to the router might require radio frequency (RF)/radio skills (typically a
non-IP and proprietary implementation). The radio–to–router physical cable might not be available
off–the–shelf.
Network Diagram
This document uses the network setup shown in the following diagram.
IP IP IP
121378
9
10
11
2
1
3
4
8
5
6
7

Cisco 2800 Series Specifications

General

Power Supply	Internal power supply
Product Type	Router
Form Factor	Rack-mountable
Connectivity Technology	Wired
Power Device	Internal power supply
Operating System	Cisco IOS
Integrated Services	Security, voice
WAN Interfaces	T1/E1, Serial
LAN Interfaces	Fast Ethernet, Gigabit Ethernet
Expansion Slots	4
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Network/Transport Protocol	IP, TCP
Remote Management Protocol	SNMP, Telnet
Features	VPN support, Quality of Service (QoS), VLAN support
Voltage Required	AC 100-240 V
Security Features	Firewall, VPN, Access Control Lists (ACLs)
