Connecting Your Phone
Your system administrator will likely connect your new Cisco Unified IP Phone to the corporate IP
telephony network. If that is not the case, refer to the graphic and table below to connect your phone.
1
DC Adaptor port (DC48V) (optional)
2
Network port (10/100 SW)
3
Access port (10/100 PC)
4
Headset port
5
Handset port
10/100 SW 10/100 PC
DC48V
170686
1
2
5
4
3
