Table 20: NTP Configuration Menu Options
To ChangeDescriptionOption
From Cisco Unified Communications Manager
Administration, choose System > Phone NTP
Reference.
IP address of the primary NTP
server.
NTP IP Address 1
From Cisco Unified Communications Manager
Administration, choose System > Phone NTP
Reference.
IP address of the secondary or
backup NTP server.
NTP IP Address 2
From Cisco Unified Communications Manager
Administration, choose System > Phone NTP
Reference.
Primary server mode. Supported
modes are Directed Broadcast,
Unicast, Multicast, Any cast.
NTP Mode 1
From Cisco Unified Communications Manager
Administration, choose System > Phone NTP
Reference.
Secondary server mode. Supported
modes are Directed Broadcast,
Unicast, Multicast, Any cast.
NTP Mode 2
UI Configuration Menu
The UI Configuration menu displays the status of various user interface features on the phone. The following
table describes the fields in this menu.
Table 21: UI Configuration Menu Options
To ChangeDescriptionOption
From Cisco Unified
Communications Manager
Administration, choose Device >
Phone > Phone Configuration.
Indicates if the phone shifts the call focus
to incoming calls on all lines.
When this option is disabled, the phone only
shifts the call focus to incoming calls on the
line that is in use. When this option is
enabled, the phone shifts the call focus to
the line with the most recent incoming call.
Default: Disabled
Auto Line Select
From Cisco Unified
Communications Manager
Administration, choose System >
Enterprise Parameters.
Indicates if the Busy Lamp Field (BLF) is
enabled for call lists.
BLF for Call Lists
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco
Unified Communications Manager 9.0 (SCCP and SIP)
92
Cisco Unified IP Phone Settings
UI Configuration Menu

Cisco 7941G Specifications

General

Keypad number of keys	12
Touchscreen	-
Display resolution	320 x 222 pixels
Speakerphone	Yes
Voice codecs	G.729a
Bluetooth	No
Supported network protocols	DHCP, TFTP, SCCP, DSCP
Ethernet LAN (RJ-45) ports	2
Input voltage	48 V
Dimensions (WxDxH)	266.7 x 152.4 x 203.2 mm
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Safety	(UL) 60950, (CSA) C22.2 No. 60950, IEC 60950, EN 60950, AS/NZS 60950
Certification	CE (FCC) 15 (CFR 47) B ICES-003 B EN55022 B CISPR22 B AS/NZ 3548 B VCCI B EN55024 EN 50082-1 EN 61000-3-2 EN 61000-3-3
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3af
Lines quantity	- lines
Phonebook capacity	- entries
Number of handles included	1 pc(s)

Weight and Dimensions

Weight	1600 g
