Network Configuration Area
The Network Configuration area on a phone’s web page displays network configuration information and
information about other phone settings. The following table describes these items.
You can view and set many of these items from the Network Configuration Menu and the Device Configuration
Menu on the Cisco Unified IP Phone. For more information, see Features, Templates, Services, and Users,
on page 119.
To display the Network Configuration area, access the web page for the phone as described in Access Web
Page for Phone, on page 192, and then click the Network Configuration hyperlink.
Table 45: Network Configuration Area Items
DescriptionItem
IP address of the Dynamic Host Configuration Protocol (DHCP) server
from which the phone obtains its IP address.
DHCP Server
Indicates that the phone obtains configuration from a Bootstrap Protocol
(BootP) server.
BOOTP Server
Media Access Control (MAC) address of the phone.MAC Address
Host name that the DHCP server assigned to the phone.Host Name
Name of the Domain Name System (DNS) domain in which the phone
resides.
Domain Name
Internet Protocol (IP) address of the phone.IP Address
Subnet mask used by the phone.Subnet Mask
Primary Trivial File Transfer Protocol (TFTP) server used by the phone.TFTP Server 1
Default router used by the phone (Default Router 1) and optional backup
routers (Default Router 2–5).
Default Router 1–5
Primary Domain Name System (DNS) server (DNS Server 1) and optional
backup DNS servers (DNS Server 2–5) used by the phone.
DNS Server 1–5
Auxiliary Virtual Local Area Network (VLAN) configured on a Cisco
Catalyst switch in which the phone is a member.
Operational VLAN ID
Auxiliary VLAN in which the phone is a member.Admin. VLAN ID
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco
Unified Communications Manager 9.0 (SCCP and SIP)
196
Remote Monitoring
Network Configuration Area

Cisco 7941G Specifications

General

Keypad number of keys	12
Touchscreen	-
Display resolution	320 x 222 pixels
Speakerphone	Yes
Voice codecs	G.729a
Bluetooth	No
Supported network protocols	DHCP, TFTP, SCCP, DSCP
Ethernet LAN (RJ-45) ports	2
Input voltage	48 V
Dimensions (WxDxH)	266.7 x 152.4 x 203.2 mm
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Safety	(UL) 60950, (CSA) C22.2 No. 60950, IEC 60950, EN 60950, AS/NZS 60950
Certification	CE (FCC) 15 (CFR 47) B ICES-003 B EN55022 B CISPR22 B AS/NZ 3548 B VCCI B EN55024 EN 50082-1 EN 61000-3-2 EN 61000-3-3
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3af
Lines quantity	- lines
Phonebook capacity	- entries
Number of handles included	1 pc(s)

Weight and Dimensions

Weight	1600 g
