Cisco 7941G Administration Guide

DescriptionItem
Total number of LLDP frames sent out from the phoneLLDP
FramesOutTotal
Total number of LLDP frames that have been time out in cacheLLDP AgeoutsTotal
Total number of LLDP frames that are discarded when any of the mandatory TLVs
is missing or out of order or contains out of range string length.
LLDP
FramesDiscardedTotal
Total number of LLDP frames that received with one or more detectable errorsLLDP
FramesInErrorsTotal
Total number of LLDP frames received on the phone.LLDP
FramesInTotal
Total number of LLDP TLVs that are discarded.LLDP
TLVDiscardedTotal
Total number of LLDP TLVs that are not recognized on the phone.LLDP
TLVUnrecognizedTotal
Identifier of a device connected to this port discovered by CDP protocol.CDP Neighbor
Device ID
IP address of the neighbor device discovered by CDP protocol.CDP Neighbor IP
Address
Neighbor device port to which the phone is connected discovered by CDP protocol.CDP Neighbor Port
Identifier of a device connected to this port discovered by LLDP protocol.LLDP Neighbor
Device ID
IP address of the neighbor device discovered by LLDP protocol.LLDP Neighbor IP
Address
Neighbor device port to which the phone is connected discovered by LLDP protocol.LLDP Neighbor
Port
Device Logs Area
The following device logs hyperlinks on a phone’s web page provide information you can use to help monitor
and troubleshoot the phone. To access a device log area, access the web page for the phone as described in
the Access Web Page for Phone, on page 192.
•
Console Logs: Includes hyperlinks to individual log files. The console log files include debug and error
messages received on the phone.
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
203
Remote Monitoring
Device Logs Area

Cisco 7941G Specifications

General

Keypad number of keys	12
Touchscreen	-
Display resolution	320 x 222 pixels
Speakerphone	Yes
Voice codecs	G.729a
Bluetooth	No
Supported network protocols	DHCP, TFTP, SCCP, DSCP
Ethernet LAN (RJ-45) ports	2
Input voltage	48 V
Dimensions (WxDxH)	266.7 x 152.4 x 203.2 mm
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Safety	(UL) 60950, (CSA) C22.2 No. 60950, IEC 60950, EN 60950, AS/NZS 60950
Certification	CE (FCC) 15 (CFR 47) B ICES-003 B EN55022 B CISPR22 B AS/NZ 3548 B VCCI B EN55024 EN 50082-1 EN 61000-3-2 EN 61000-3-3
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3af
Lines quantity	- lines
Phonebook capacity	- entries
Number of handles included	1 pc(s)

Weight and Dimensions

Weight	1600 g
