Cisco 7941G Administration Guide

Phone Startup Process Verification
After the Cisco Unified IP Phone has power connected to it, the phone begins its startup process by cycling
through the following steps.
1
These buttons flash on and off in sequence:
•
Headset (only if the handset is off-hook when the phone powers up. Hang up the handset within 3
seconds to have the phone launch its secondary load. To continue with the primary load, leave the
handset off-hook.)
•
Mute
•
Speaker
2
Some or all of the line keys flash amber in sequence.
If the line keys flash red in sequence after flashing amber, do not power down the phone until the sequence
of red flashes completes. This sequence can take several minutes to complete.
Caution
3
Some or all of the line keys flash green.
Normally, this sequence takes just a few seconds. However, if the phone’s Flash memory is erased or the
phone load is corrupted, the sequence of green flashes will continue while the phone begins a software
update procedure. If the phone performs this procedure, the following buttons light to indicate progress:
• Headset—Phone is waiting for the network and completing CDP and DHCP configuration. A DHCP
server must be available in your network.
• Mute—Phone is downloading images from the TFTP server.
• Speaker—Phone is writing images to its Flash memory.
4
The phone screen displays the Cisco Systems, Inc., logo screen.
5
These messages appear as the phone starts:
•
Verifying Load (if the phone load does not match the load on the TFTP server). If this message
appears, the phone starts up again and repeats step 1 through step 4 above.
•
Configuring IP
•
Updating the Trust List
•
Updating Locale
•
Configuring Unified CM List
•
Registering
6
The phone screen displays:
•
Current date and time
•
Primary directory number
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco
Unified Communications Manager 9.0 (SCCP and SIP)
56
Cisco Unified IP Phones Installation
Phone Startup Process Verification

Cisco 7941G Specifications

General

Keypad number of keys	12
Touchscreen	-
Display resolution	320 x 222 pixels
Speakerphone	Yes
Voice codecs	G.729a
Bluetooth	No
Supported network protocols	DHCP, TFTP, SCCP, DSCP
Ethernet LAN (RJ-45) ports	2
Input voltage	48 V
Dimensions (WxDxH)	266.7 x 152.4 x 203.2 mm
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Safety	(UL) 60950, (CSA) C22.2 No. 60950, IEC 60950, EN 60950, AS/NZS 60950
Certification	CE (FCC) 15 (CFR 47) B ICES-003 B EN55022 B CISPR22 B AS/NZ 3548 B VCCI B EN55024 EN 50082-1 EN 61000-3-2 EN 61000-3-3
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3af
Lines quantity	- lines
Phonebook capacity	- entries
Number of handles included	1 pc(s)

Weight and Dimensions

Weight	1600 g
