Cisco 7941G Administration Guide

DescriptionItem
Version of the user locale loaded on the phone.User Locale Version
Version of the network locale loaded on the phone.Network Locale Version
Indicates if the PC port on the phone is enabled or disabled.PC Port Disabled
Indicates if the speakerphone is enabled on the phone.Speaker Enabled
Indicates if the phone learns MAC addresses from Gratuitous ARP
(GARP) responses.
GARP Enabled
Indicates if the phone can participate in video calls when connected to
an appropriately equipped PC.
Video Capability Enabled
Indicates if the phone allows a device attached to the PC port to access
the Voice VLAN.
Voice VLAN Enabled
Indicates if the phone shifts the call focus to incoming calls on all lines.Auto Line Select
DSCP IP classification for call control signaling.DSCP for Call Control
DSCP IP classification for any phone configuration transfer.DSCP for Configuration
DSCP IP classification for phone-based services.DSCP for Services
Displays the security mode that is set for the phone.Security Mode
Indicates if web access is enabled (Yes) or disabled (No) for the phone.Web Access Enabled
Indicates if the phone will forward packets transmitted and received on
the network port to the access port.
Span to PC Port
VLAN used to identify and remove 802.1P/Q tags from packets sent to
the PC.
PC VLAN
Indicates if the internal switch begins forwarding packets between the
PC port and switched port on the phone when the phone becomes active.
Forwarding Delay
Indicates if Link Layer Discovery Protocol (LLDP) is enabled on the PC
port.
LLDP: PC Port
Indicates if Link Layer Discovery Protocol Media Endpoint Discovery
(LLDP-MED) is enabled on the switch port.
LLDP-MED: SW Port
Identifies the asset ID assigned to the phone for inventory management.LLDP Asset ID
Enables users to receive notifications of incoming calls and answer or
end calls while working in a wireless environment.
Wireless Headset Hookswitch
Control
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
199
Remote Monitoring
Network Configuration Area

Cisco 7941G Specifications

General

Keypad number of keys	12
Touchscreen	-
Display resolution	320 x 222 pixels
Speakerphone	Yes
Voice codecs	G.729a
Bluetooth	No
Supported network protocols	DHCP, TFTP, SCCP, DSCP
Ethernet LAN (RJ-45) ports	2
Input voltage	48 V
Dimensions (WxDxH)	266.7 x 152.4 x 203.2 mm
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Safety	(UL) 60950, (CSA) C22.2 No. 60950, IEC 60950, EN 60950, AS/NZS 60950
Certification	CE (FCC) 15 (CFR 47) B ICES-003 B EN55022 B CISPR22 B AS/NZ 3548 B VCCI B EN55024 EN 50082-1 EN 61000-3-2 EN 61000-3-3
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3af
Lines quantity	- lines
Phonebook capacity	- entries
Number of handles included	1 pc(s)

Weight and Dimensions

Weight	1600 g
