To ChangeDescriptionOption
Set PC VLAN Field, on page 77Allows the phone to interoperate with
third-party switches that do not support a voice
VLAN. The Admin VLAN ID option must be
set before you can change this option.
PC VLAN
Display only—Cannot configure.
Shows the virtual private network (VPN) Client
state:
•
Connected
•
Not Connected
(Supported only for the Cisco Unified IP Phone
7942G, and 7962G.)
VPN
The following table describes the IPv4 configuration menu options.
Table 10: IPv4 Configuration Menu Options
To ChangeDescriptionOption
Set DHCP Field, on page 77Indicates whether the phone has DHCP
enabled or disabled.
When DHCP is enabled, the DHCP server
assigns the phone anIPv4 address. When
DHCP is disabled, you manually assign
an IPv4 address to the phone.
DHCP
Set IP Address Field, on page 77Internet Protocol version 4 (IPv4) address
of the phone.
If you assign an IPv4 address with this
option, you must also assign a subnet
mask and default router. See Subnet Mask
and Default Router 1 options in this table.
IP Address
Set Subnet Mask Field, on page 78Subnet mask used by the phone.Subnet Mask
Set Default Router Fields, on page 78Default router used by the phone (Default
Router 1) and optional backup routers
(Default Router 2–5).
Default Router 1
Default Router 2
Default Router 3
Default Router 4
Default Router 5
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
67
Cisco Unified IP Phone Settings
Network Configuration Menu
