Cisco 7961G Administration Guide

Chapter 4 Configuring Settings on the Cisco IP Phone
Network Configuration Menu
4-14
Cisco IP Phone Administration Guide for Cisco CallManager, Cisco IP Phone 7961G/7961G-GE and 7941G/7941G-GE
OL-6966-01
PC Port
Configuration
Speed and duplex of the access port
(labeled 10/100 PC on the 7961G and
7941G; labeled 10/100/100 PC on the
7961G-GE and 7941G-GE). Valid
values:
• Auto Negotiate
• 10 Half—10-BaseT/half duplex
• 10 Full—10-BaseT/full duplex
• 100 Half—100-BaseT/half
duplex
• 100 Full—100-BaseT/full
duplex
• 1000 Full—1000-BaseT/full
duplex
If the phone is connected to a switch,
configure the port on the switch to
the same speed/duplex as the phone,
or configure both to auto-negotiate.
If you change the setting of this
option, you must change the SW Port
Configuration option to the same
setting.
1. Unlock network configuration options.
2. Scroll to the PC Port Configuration
option and then press the Edit softkey.
3. Scroll to the setting that you want and
then press the Select softkey.
4. Press the Save softkey.
PC VLAN Allows the phone to work better with
non-Cisco switches. Strips the
802.1P/Q tags from the packets going
to a PC from the access port on the
phone.
The Admin VLAN ID must be set
before using this option.
1. Unlock network configuration options.
2. Make sure the Admin VLAN ID is set
(see Admin VLAN ID above in this
table).
3. Scroll to the PC VLAN option, press
the Edit softkey, and then enter a new
PC VLAN setting.
4. Press the Validate softkey and then
press the Save softkey.
Table 4-2 Network Configuration Menu Options (continued)
Option Description To Change
