D-5

Cisco Aironet 1100 Series Access Point Installation and Configuration Guide

OL-2851-01

Appendix D Mounting Instructions

Mounting on a Suspended Ceiling

Step 8 Line up the mounting slots on the access point with the mounting rail on the wall or ceiling mounting

bracket and slide it down the mounting rails until it clicks into place. See Figure D-3.

Figure D-3 Access Point Mounting Slots

81224
