4-3
Cisco Aironet 1100 Series Access Point Installation and Configuration Guide
OL-2851-01
Chapter 4 Using the Web-Browser Interface
Using the Management Pages in the Web-Browser Interface
Figure 4-1 Web-Browser Interface Home Page
Using Action Buttons
Table 4-1 lists the page links and buttons that appear on most management pages.
Table 4-1 Common Buttons on Management Pages
Button/Link Description
Navigation Links
Home Displays access point status page with information on the number of radio
devices associated to the access point, the status of the Ethernet and radio
interfaces, and a list of recent access point activity.
Express Setup Displays the Express Setup page that includes basic settings such as system
name, IP address, and SSID.
Network Map Displays a list of infrastructure devices on your wireless LAN.
Association Displays a list of all devices on your wireless LAN, listing their system names,
network roles, and parent-client relationships.
