Chapter 2 Installing the Access Point
Before Beginning the Installation
Before Beginning the Installation
Before you begin the installation process, please refer to Figure 2-1 to familiarize yourself with the
access point’s layout, features, and connectors.
Figure 2-1 Access Point Layout and Connectors
Installation Summary
During the installation of the access point, you need to perform the following operations:
• Connect Ethernet and power cables (refer to the “Connecting the Ethernet and Power Cables”
section on page 2-5).
• Configure basic settings (refer to Chapter 3, “Configuring the Access Point for the First Time”).
• Configure security and other access point options.
• Use the mounting brackets or docking cradle to locate the access point on a convenient flat
horizontal or vertical surface, such as a desktop, book shelf, file cabinet, cubicle wall, room wall, or
the room ceiling. For additional information, refer to Appendix D, “Mounting Instructions.”
1 2 3 5
81180
6
4
1 48 VDC power port 4 Mode button
2 Ethernet port (RJ-45) 5 Status LEDs
3 Cable lock slot 6 Antenna
