E-3

Cisco Aironet 1100 Series Access Point Installation and Configuration Guide

OL-2851-01

Appendix E Protocol Filters

Table E-2 IP Protocols

Protocol Additional Identifier ISO Designator

dummy — 0

Internet Control Message Protocol ICMP 1

Internet Group Management Protocol IGMP 2

Transmission Control Protocol TCP 6

Exterior Gateway Protocol EGP 8

PUP — 12

CHAOS — 16

User Datagram Protocol UDP 17

XNS-IDP IDP 22

ISO-TP4 TP4 29

ISO-CNLP CNLP 80

Banyan VINES VINES 83

Encapsulation Header encap_hdr 98

Spectralink Voice Protocol SVP

Spectralink

119

raw — 255
