Appendix G Access Point Specifications
Radio 2.4-GHz Radio
Power Output 100, 50, 30, 20, 5, or 1 mW
(Depending on the regulatory domain in which the access point is installed)
Frequency 2.400 to 2.497 GHz
(Depending on the regulatory domain in which the access point is installed)
Range Indoor:
150 ft (45 m) at 11 Mbps
400 ft (122 m) at 1 Mbps
Outdoor:
800 ft (244 m) at 11 Mbps
2000 ft (610 m) at 1 Mbps
Modulation Direct Sequence Spread Spectrum (DSSS)
Data rates 1, 2, 5.5, and 11 Mbps
Antenna A diversity system with two integrated 2.2 dBi dipole antennas.
Compliance Operates license-free under FCC Part 15 and complies as a Class B
computing device. Complies with DOC regulations. Complies with the
following: EN 300.328, FCC Part 15.107 and 15.109 Class B,
ICES-003 Class B (Canada), EN 55022 Class B, AS/NZS 3548 Class B,
VCCI Class B, EN 301.489-1 and -17, UL 60950, CSA 22.2 No. 60950,
EN 60950, IEC 60950, VCCI, FCC Part 15.247, RSS-210, RSS-139-1,
UL 2043, and others (see Appendix B).
The 1100 Series access point provides adequate fire resistance and low
smoke-producing characteristics suitable for operation in a building's
environmental air space, such as above suspended ceilings, in accordance with
Section 300-22(C) of the National Electrical Code (NEC) and Sections 2-128,
12-010(3) and 12-100 of the Canadian Electrical Code, Part 1, C22.1.
Caution Cisco Aironet 1100 series power injectors and the universal
power supplies are not tested to UL 2043 and should not be
placed in a building’s air-handling spaces, such as above
suspended ceilings.
Table G-1 Access Point Specifications (continued)
Category Specification
