Cisco ASR 900 Series Configuration Guide

PatternsModes
•
2^11 -
•
2^15- Error and Jitter measurement of 1544,
2048, 6312, 8448, 32064, 44736 kbps
•
2^20 - O.153
•
2^20-QRSS
SDH - AU-3 Mapping - AU3_T1
•
2^11 -
•
2^15- Error and Jitter measurement of 1544,
2048, 6312, 8448, 32064, 44736 kbps
•
2^20 - O.153
•
2^20-QRSS
SDH - AU-4 Mapping - AU4_E1
Restrictions for SDH BERT on CESoPSN
•
In the system-level BERT for CESoPSN, only the full timeslot is supported and the fractional timeslot
is not supported.
•
In the BERT timeslot configuration, the timeslot should be same as the one provided in the CEM
configuration.
Configuring BERT in AUG mapping AU-3 VC1x T1 for CESoPSN
To configure BERT in AUG Mapping AU-3 VC1x T1 for CESoPSN:
router#configure terminal
router(config)#controller mediatype 0/5/0
router(config)#mode sdh
router(config)#controller sdh 0/5/0
router(config)#rate stm1
router(config)#controller sdh 0/5/0
router(config-controller)#aug mapping au-3
router(config-controller)#au-3 1
router(config-ctrlr-au3)#mode vc1x
router(config-ctrlr-au3)#!
router(config-ctrlr-au3)#Tug-2 1 payload vc11
router(config-ctrlr-tug2-vcx)#T1 1 bert timeslots 1 - 7 pattern 2^11 interval 1 direction
line
router(config-ctrlr-tug2-vcx)#end
1-Port OC-192 or 8-Port Low Rate CEM Interface Module Configuration Guide, Cisco IOS XE Everest 16.7.x
(Cisco ASR 900 Series)
100
Configuring SDH on 1-Port OC-192/STM-64 or 8-Port OC-3/12/48/STM-1/-4/-16 Module
Restrictions for SDH BERT on CESoPSN
