Cisco ASR 900 Series Configuration Guide

aps adm
end
To restore the system to its default condition, use the no form of the command.Note
Verifying ACR Configurations for SAToP
This section includes show commands for ACR: The following example shows the ACR groups that have
been configured or deleted:
Router# show acr group
ACR Group Working I/f Protect I/f Currently Active Status
--------------------------------------------------------------------------
1 SONET 4/1/0 SONET 3/1/0 SONET 4/1/0
The following example shows the configured working and protect CEM interfaces under the ACR controller:
Router# show acr group 1 detail cem
ACR Group Working I/f Protect I/f Currently Active Status
--------------------------------------------------------------------------
CE1 CEM0/3/0 CEM0/12/1 CEM0/3/0
CEM CKT Details
Cktid State on Working State on Protect
1 Enable Success Enable Success
The following example shows the configuration under the ACR controller:
Router##show running-config | sec ACR
controller SONET-ACR 1
framing sonet
!
sts-1 1
mode vt-15
vtg 1 vt 1 cem-group 1 cep
!
sts-1 2
!
sts-1 3
interface CEM-ACR1
no ip address
cem 1
!
The following example shows the loopback IP address for the router:
Router# show ip interface brief | i Loopback
Loopback0 22.22.22.22 YES NVRAM up up
The following example shows the CEM-ACR circuit status:
Router# show cem circuit
CEM Int. ID Ctrlr Admin Circuit AC
--------------------------------------------------------------
CEM-ACR1 1 UP UP Active UP
CEM-ACR1 2 UP UP Active UP
CEM-ACR1 3 UP UP Active UP
CEM-ACR1 4 UP UP Active UP
CEM-ACR1 5 UP UP Active UP
CEM-ACR1 6 UP UP Active UP
CEM-ACR1 7 UP UP Active UP
CEM-ACR1 8 UP UP Active UP
The following example shows the CEM-ACR circuit details for CEM group 0 under the CEM-ACR interface:
Router# #show cem circuit interface cem-acr 1 1
CEM-ACR1, ID: 1, Line: UP, Admin: UP, Ckt: ACTIVE
1-Port OC-192 or 8-Port Low Rate CEM Interface Module Configuration Guide, Cisco IOS XE Everest 16.7.x (Cisco
ASR 900 Series)
41
Configuring SONET
Managing and Monitoring SONET Line
