Cisco ASR 900 Series Configuration Guide

Configuring CEM Group for Sonet Mode VT1.5-T1 in CESoPSN
To configure CEM group in VT 1.5 mode of STS-1 for CESoPSN, use the following commands:
enable
configure terminal
controller sonet 0/5/0
sts-1 2
mode vt-15
vtg 1 t1 1 cem-group 56 timeslots 1 - 8
end
Configuring CEM Group for Sonet Mode CT3-T1 in CESoPSN
To configure CEM group in CT3 mode of STS-1 for CESoPSN, use the following commands:
enable
configure terminal
controller sonet 0/5/0
sts-1 1
mode ct3
t1 3 cem-group 28 timeslots 1 - 7
end
Configuring APS for SAToP
This section describes the configuration of APS for SAToP.
Configuring Bi-directional ACR (SONET Framing) for SAToP
To configure bi-directional ACR (SONET Framing), use the following commands:
enable
configure terminal
controller sonet 0/5/0
clock source internal
aps group acr 1
aps working 1
exit
controller sonet 0/4/0
aps group acr 1
aps protect 1 10.7.7.7
end
To restore the system to its default condition, use the no form of the command.Note
Configuring Unidirectional APS for SAToP
To configure unidirectional ACR (SONET Framing), use the following commands:
enable
configure terminal
controller sonet 0/5/0
clock source internal
aps group acr 1
aps working 1
aps unidirectional
exit
controller sonet 0/5/0
aps group acr 1
aps protect 1 10.7.7.7
aps revert 3
1-Port OC-192 or 8-Port Low Rate CEM Interface Module Configuration Guide, Cisco IOS XE Everest 16.7.x
(Cisco ASR 900 Series)
40
Configuring SONET
Managing and Monitoring SONET Line
