Software Upgrade Process
Upgrade Process With Service Impact for Nonredundant Platforms
82
Cisco ASR 1000 Series Aggregation Services Routers Software Configuration Guide
Step 6
request platform software package expand file
URL-to-consolidated-package
(Optional) dir target-URL
Example:
Router# request platform software package expand
file
usb0:221subs/asr1001-universalk9.03.02.01.S.151-1.S
1_2.bin
Router# dir 221subs
Extract the subpackages out of the consolidated package
file into the temporary directory.
Note Take extra care to extract the subpackages to a
temporary subdirectory and do not delete any of
the files currently running the router at this point
of the procedure.
To erase the files that were running on the router
before t
he ISSU upgrade, enter the request
platform software package clean command
after the ISSU upgrade has been completed.
Step 7
dir target-URL
Example:
Router# dir 221subs
(Optional) Display the directory to confirm that the files
were extracted.
Step 8
copy file-system:asr1001-espbase.version.pkg
URL-to-directory-of-sub-packages-active-RP
copy file-system:asr1001-rp
access.version.pkg
URL-to-directory-of-sub-packages-active-RP
copy file-system:asr1001-rp
base.version.pkg
URL-to-directory-of-sub-packages-active-RP
copy file-system:asr1001-rp
control.version.pkg
URL-to-directory-of-sub-packages-active-RP
copy file-system:asr1001-rp
ios.version.pkg
URL-to-directory-of-sub-packages-active-RP
copy file-system:asr1001-si
pbase.version.pkg
URL-to-directory-of-sub-packages-active-RP
copy file-system:asr1001-si
pspa.version.pkg
URL-to-directory-of-sub-packages-active-RP
Example:
Router# copy
221subs/asr1001-espbase.03.02.01.S.151-1.S1_2.pkg
bootflash:
Router# copy
22
1subs/asr1001-rpaccess.03.02.01.S.151-1.S1_2.pkg
bootflash:
Router# copy
22
1subs/asr1001-rpbase.03.02.01.S.151-1.S1_2.pkg
bootflash:
Router# copy
22
1subs/asr1001-rpcontrol.03.02.01.S.151-1.S1_2.pkg
bootflash:
Router# copy
22
1subs/asr1001-rpios-universalk9.03.02.01.S.151-1.
S1_2.pkg bootflash:
Router# copy
22
1subs/asr1001-sipbase.03.02.01.S.151-1.S1_2.pkg
bootflash:
Router# copy
22
1subs/asr1001-sipspa.03.02.01.S.151-1.S1_2.pkg
bootflash:
Copy the subpackages out of the temporary directory
into the directory on the router where the subpackages
running the active RP are currently stored.
Command or Action Purpose
