Cisco ASR1002 - ASR 1002 Router - Configuring a Console Port Transport Map; Examples

Console Port, Telnet, and SSH Handling
Configuring a Console Port Transport Map
3
Cisco ASR 1000 Series Aggregation Services Routers Software Configuration Guide
Configuring a Console Port Transport Map
This task describes how to configure a transport map for a console port interface on the Cisco ASR 1000
Series Router.
SUMMARY STEPS
1. (Required) enable
2. (Required) configure terminal
3. (Required) transport-map type console transport-map-name
4. (Required) connection wait [allow interruptible | none {disconnect}]
5. (Optional) banner [diagnostic | wait] banner-message
6. (Required) exit
7. (Required) transport type console console-line-number input transport-map-name
DETAILED STEPS
Command or Action Purpose
Step 1
enable
Example:
Router> enable
Enables privileged EXEC mode.
• Enter your password if prompted.
Step 2
configure terminal
Example:
Router# configure terminal
Enters global configuration mode.
Step 3
transport-map type console transport-map-name
Example:
Router(config)# transport-map type console
consolehandler
Creates and names a transport map for handling console
connections, and enter transport map configuration mode.
Step 4
connection wait [allow interruptible | none]
Example:
Router(config-tmap)# connection wait none
Specifies how a console connection will be handled using
this transport map:
• allow interruptible—The console connection waits for
an IOS vty line to become available, and also allows
user to enter diagnostic mode by interrupting a console
connection waiting for the IOS vty line to become
available. This is the default setting.
Note Users can interrupt a waiting connection by
entering Ctrl-C or Ctrl-Shift-6.
• none—The console connection immediately enters
diagnostic mode.
