Configuring MPLS Layer 2 VPNs
Additional References
30
Cisco ASR 1000 Series Aggregation Services Routers Software Configuration Guide
Note Ethernet-to-EtherChannel over MPLS (Bridge) Interworking mode is also supported under VLAN.
Additional References
The following sections provide references related to the Frame Relay to ATM Bridged Interworking and
xconnect support on GEC (VPWS) features.
Related Documents
Standards
MIBs
Step 23
clock source internal
Specifies that the T1/E1 link uses the internal clock
from the interface.
Step 24
xconnect peer-loopback vc-id pw-class pe-class-name
Binds an attachment circuit to a pseudowire to
configure an AToM static pseudowire, specifies
MPLS as the tunneling method, and enters the
xconnect configuration mode.
Command or Action Purpose
Related Topic Document Title
Cisco IOS commands Cisco IOS Master Commands List, All Releases
Basics of MPLS MPLS: Basic MPLS Configuration Guide, Cisco IOS XE Release 3S
MPLS Layer 2 VPNs MPLS Layer 2 VPNs Configuration Guide, Cisco IOS XE Release 3S
Cisco IOS Configuration Fundamentals Cisco IOS Configuration Fundamentals Command Reference
Standard Title
No new or modified standards are s
upported by this
feature.
—
MIB MIBs Link
• CISCO-IETF-PW-MIB
• CISCO-IETF-PW-MPLS-MIB
To locate and download MIBs for selected platforms, Cisco IOS
release
s, and feature sets, use the Cisco MIB Locator found at the
fo
llowing URL:
http://www.cisco.com/go/mibs
