Cisco ASR1002 - ASR 1002 Router Software Configuration Guide

Configuring Bridge Domain Interfaces
How to Configure a Bridge Domain Interface
8
Cisco ASR 1000 Series Aggregation Services Routers Software Configuration Guide
DETAILED STEPS
Example
The following example shows the configuration of a bridge domain interface at IP address 2.2.2.1
255.255.255.0:
Router# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Router(config)# interface BDI3
Router(config-if)# encapsulation dot1Q 1 second-dot1q 2
Router(config-if)# ip address 2.2
.2.1 255.255.255.0
Router(config-if)# mac-address 1.
1.3
Router(config-if)# no shut
Command or Action Purpose
Step 1
configure terminal
Example:
Router# configure terminal
Enters the global configuration mode.
Step 2
interface BDI {interface number}
Example:
Router(config)# interface BDI3
Specifies a bridge domain interface on a Cisco ASR 1000
Series Aggregation Services Router.
Step 3
encapsulation encapsulation dot1q <first-tag>
[second-dot1q <second-tag>]
Example:
Router(config-if)#encapsulation dot1Q 1
second-dot1q 2
Defines the encapsulation type.
The example shows how to define dot1q as the
enca
psulation type.
Step 4
ip address ip-address mask
or
ipv6 address {X:X:X:X::X link-local |
X:X:X:X::X/prefix [anycast | eui-64] | autoconfig
[default]}
Example:
Router(config-if)# ip address 2.2.2.1
255.255.255.0
Specifies either the IPv4 or IPv6 address for the bridge
domain interface.
Step 5
mac-address {mac-address}
Router(config-if)# mac-address 1.1.
3
Specifies the MAC address for the bridge domain
interface.
Step 6
no shut
Example:
hostname(config-if)# no shut
Enables the bridge domain interface on the Cisco ASR
1000 Series Aggregation Services Router.
Step 7
shut
Example:
hostname(config-if)# shut
Disables the bridge domain interface on the Cisco ASR
1000 Series Aggregation Services Router.
