--Two 10-32 Phillips pan-head screws1
Step 4 Mount the magnet and the switch on a metal surface.
Read the wall-mounting instructions carefully before beginning installation. Failure to use the correct
hardware or to follow the correct procedures could result in a hazardous situation to people and
damage to the system. Statement 378
Warning
Do not wall-mount the switch with its front panel facing up. Following safety regulations, wall-mount
the switch with its front panel facing down or to the side, to allow sufficient airflow and to provide
easier access to the cables.
Caution
To prevent airflow restriction, allow clearance around the ventilation openings to be at least: 3 in.
(7.6 cm) Statement 1076
Warning
Ensure that you mount the switch in an enclosed and secure area. Pulling the cables hard or an
occurance of a seismic event can cause the magnet to dislodge from the mounting surface and cause
bodily harm.
Danger
Mounting Under a Desk or a Shelf
Before you begin
Ensure you have the following items before starting the procedure.
• Desk mount (C9K-CMPCT-DESK-MNT)
• Three 8-18 Phillips pan-head screws
• Two 10-32 Phillips pan-head screws
• Screwdriver
Procedure
Step 1 Use the desk mount to align the screw holes and also as a guide to make sure that you install the screws under
the desk or shelf with proper clearance.
Step 2 Use a 0.144-inch (3.7 mm) or a #27 drill bit to drill three holes, 1/2-inches (12.7 mm) deep on the desk or
shelf.
Step 3 Insert the screws in to the slots on the desk mount, and tighten them.
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
58
Installing a Compact Switch
Mounting Under a Desk or a Shelf
