Cisco Catalyst 9200 Series Hardware Installation Guide

Figure 44: Locking the Retainer Clamp
--Pressing the tabs on the
retainer clamp
1
Installing the Cable Guard (Optional)
The cable guard prevents tampering with the cables after they are installed. The cable guard
(C9K-CMPCT-CBLE-GRD=) is not included with the switch, but you can order it from your Cisco
representative.
You can use the cable guard when the switch is mounted on a wall.
Note
The cable guard is shipped with the following items:
• Two 10-32 Phillips pan-head screws
• Two 8-18 Phillips pan-head screws
Procedure
Step 1 Use the supplied 10-32 pan-head screws to attach the cable guard to the switch.
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
71
Installing a Compact Switch
Installing the Cable Guard (Optional)

Cisco Catalyst 9200 Series Specifications

General

Category	Switch
Stacking Bandwidth	160 Gbps
Layer	Layer 2 and Layer 3
Operating System	Cisco IOS XE
Operating Temperature	0°C to 45°C (32°F to 113°F)
Series	Cisco Catalyst 9200 Series
Ports	24 or 48 Ethernet ports
Switching Capacity	Up to 176 Gbps
PoE	PoE, PoE+, and UPOE
Stacking	StackWise-160
Memory	4 GB DRAM, 4 GB Flash
Network Management	Cisco DNA Center, WebUI, CLI
Security Features	802.1X, TrustSec, MACsec
Warranty	Limited Lifetime Warranty
Dimensions	1.73 x 17.5 x 11.3 in. (4.4 x 44.5 x 28.8 cm)
