Cisco Catalyst 9200 Series Hardware Installation Guide

Figure 57: 125W AC Power Supply
AC OK LED3Release latch1
PS OK LED4AC power cord connector2
If no power supply is installed in a power supply slot, install a power supply slot cover.
Figure 58: Power Supply Slot Cover
Retainer clips2Release handles1
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
89
Installing a Power Supply Unit
Power Supply Modules Overview

Cisco Catalyst 9200 Series Specifications

General

Category	Switch
Stacking Bandwidth	160 Gbps
Layer	Layer 2 and Layer 3
Operating System	Cisco IOS XE
Operating Temperature	0°C to 45°C (32°F to 113°F)
Series	Cisco Catalyst 9200 Series
Ports	24 or 48 Ethernet ports
Switching Capacity	Up to 176 Gbps
PoE	PoE, PoE+, and UPOE
Stacking	StackWise-160
Memory	4 GB DRAM, 4 GB Flash
Network Management	Cisco DNA Center, WebUI, CLI
Security Features	802.1X, TrustSec, MACsec
Warranty	Limited Lifetime Warranty
Dimensions	1.73 x 17.5 x 11.3 in. (4.4 x 44.5 x 28.8 cm)
