• By connecting a control device to the Cisco device through an
internet connection (Internet access)
7.2.1. Local access and login for initial configuration
NOTE
If your computer has a wireless WiFi card, you may have to
disable the card to avoid routing issues between the
computer's wired and wireless network interfaces.
To use the Configurator interface to access the Cisco FM4200 Fiber
directly, do the steps that follow:
Power ON the unit.1.
2. sequence toboottheforminuteoneWait approximately
complete.
Connect one end of a CAT5/6 Ethernet cable to the computer that3.
will be used to configure the Cisco FM4200 Fiber.
4. Connect the other end of the Ethernet cable to the Console LAN
port on the Cisco FM4200 Fiber.
5. Manually set the computer's IP address and Netmask to be
recognizable by the Cisco FM4200 Fiber. The correct settings are
as follows:
• IP address: 192.168.0.10 (or any other IP address
belonging to subnet 192.168.0.0/255.255.255.0)
• Netmask: 255.255.255.0
Launch the computer's web browser.6.
7. Enter the IP address of the Cisco FM4200 Fiber in the browser's
URL entry field.
• If the Configurator interface is shown immediately, proceed
to Step 9 below.
• Alternatively, you may see the following window:
Device configuration using the configurator interface
© 2021 Cisco and/or its affiliates. All rights reserved. Page 58 of 189
