Cisco Line Card 4500 E-Series User Manual

1-11
Catalyst 4500 E-Series Switches Installation Guide
OL-13972-02
Chapter 1 Product Overview
Catalyst 4507R-E Switch
Ta b l e 1-5 Catalyst 4507R-E Switch Features
Feature Description
Chassis Seven horizontal slots. Slots are numbered from 1 (top) to 7 (bottom).
Supervisor engines • Supports the following supervisor engines:
– Supervisor Engine 7-E
– Supervisor Engine 6L-E
– Supervisor Engine 6-E
– Supervisor Engine V-10GE
– Supervisor Engine V
– Supervisor Engine IV
– Supervisor Engine II-Plus-10GE
– Supervisor Engine II-Plus
Note Refer to your software release notes for the minimum software
release versions required to support the supervisor engines.
• Supervisor engines must be installed in slot 3 and in slot 4.
• Supervisor engine redundancy is supported in this chassis.
Note The Catalyst 4507R-E switch supports 1+1 supervisor-engine
redundancy for integrated resiliency. Redundant supervisor engines
help minimize network downtime. With the support of stateful
switchover (SSO), the secondary supervisor engine serves as a
backup to immediately take over after a primary supervisor failure.
During the switchover, Layer 2 links are maintained transparently
without the need to renegotiate sessions.
Modules • Supports up to six Catalyst 4500 series modules.
• Some Catalyst 4500 series modules may:
– Not be supported
– Require that you install a specific supervisor engine
– Have chassis slot restrictions
– Require a specific software release level to operate
• Check your software release notes for specific information.
Backplane 24 Gbps full duplex per slot (240 Gbps).

Cisco Line Card 4500 E-Series Specifications

General

Brand	Cisco
Model	Line Card 4500 E-Series
Category	Switch
Language	English
