Cisco Line Card 4500 E-Series User Manual

1-22
Catalyst 4500 E-Series Switches Installation Guide
OL-13972-02
Chapter 1 Product Overview
Catalyst 4507R+E Switch
Table 1-6 lists the environmental and physical specifications of the Catalyst 4507R+E switch.
Power supply • Supports one or two power supplies. The following power supplies are
supported:
– 1000 W AC-input power supply (PWR-C45-1000AC)
– 1400 W AC-input power supply (PWR-C45-1400AC)
– 1300 W AC-input power supply (PWR-C45-1300ACV)
– 2800 W AC-input power supply (PWR-C45-2800ACV)
– 4200 W AC-input power supply (PWR-C45-4200ACV)
– 6000 W AC-input power supply (PWR-C45-6000ACV)
– 1400 W DC-input power supply, triple-input (PWR-C45-1400DC)
– 1400 W DC-input power supply with integrated PEM
(PWR-C45-1400DC-P)
– External AC power shelf (WS-P4502-1PSU)
• All Catalyst 4500 series AC-input power supplies require single-phase
source AC. Source AC can be out of phase between multiple power
supplies or multiple AC-power plugs on the same power supply because
all AC power supply inputs are isolated.
• Single power supplies are installed in the left power supply bay. The
second power supply is installed in the right power supply bay.
Note For proper operation of the power supply OUTPUT FAIL LED,
systems with single power supplies must be configured with a
minimum of one fan tray and one supervisor engine. Systems with
dual power supplies must have a minimum configuration of one fan
tray, one supervisor engine, and one additional module. Failure to
meet these minimum configuration requirements can cause a false
power supply output fail signal.
Table 1-9 Catalyst 4507R+E Switch Features (continued)
Feature Description
Ta b l e 1-10 Catalyst 4507R+E Switch Specifications
Item Specification
Temperature, ambient • Operating: 32° to 104°F (0° to 40°C)
• Nonoperating and storage: –40° to 167°F (–40° to 75°C)
Humidity (RH), ambient
(noncondensing)
• Operating: 10% to 90%
• Nonoperating and storage: 5% to 95%
Altitude,
operating and nonoperating
–196 to 6561 ft (–60 to 2000 m)
Sound pressure level • One PS: 63.6 dBA at low speed and 68.3 dBA at full speed
• Two PS: 65.4 dBA at low speed and 68.4 dBA at full speed
