Cisco MDS 9000 Series Troubleshooting Guide

CHAPTER
Send comments to mdsfeedback-doc@cisco.com.
7-61
Cisco MDS 9000 Family Troubleshooting Guide
OL-5183-02, Cisco MDS SAN-OS Release 1.3
7
Troubleshooting Fabric Manager Issues
This chapter contains some common issues you may experience while using Cisco Fabric Manager, and
provides solutions.
This chapter contains the following topics:
• Can I Set the Map Layout So It Stays After I Restart Fabric Manager?, page 7-61
• Two Switches Show on my Map, But I Only Have One Switch, page 7-62
• There is a Red Line Through the Switch. What’s Wrong?, page 7-62
• There is a Dotted Orange Line Through the Switch. What’s Wrong?, page 7-62
• Can I Upgrade Without Losing My Map Settings?, page 7-62
• Are There Any Restrictions When Using Fabric Manager Across FCIP?, page 7-62
• Running Cisco Fabric Manager with Multiple Interfaces, page 7-63
• Configuring a Proxy Server, page 7-64
• Clearing Topology Maps, page 7-64
• Can I Use Fabric Manager in a Mixed Software Environment?, page 7-65
Can I Set the Map Layout So It Stays After I Restart Fabric
Manager?
If you have arranged the map to your liking and would like to “freeze” the map so that the objects stay
as they are even after you stop Fabric Manager and restart it again, do the following:
Step 1 Right-click on a blank space in the map. A menu is displayed.
Step 2 Select Layout -> Fix All Nodes from the menu.

Cisco MDS 9000 Series Specifications

General

Category	Switch
Operating System	Cisco NX-OS
Ports	Varies by model
Protocols	Fibre Channel (FC), Fibre Channel over IP (FCIP), iSCSI
Redundancy	Redundant supervisors, power supplies, and fans
Management	Cisco Data Center Network Manager (DCNM), CLI, SNMP
Virtualization Support	VSANs (Virtual SANs)
Security Features	Fibre Channel Security Protocol (FC-SP)
Hot Swappable Components	power supplies, fans
Power Supply Options	AC and DC options available
