CHAPTER
Send comments to mdsfeedback-doc@cisco.com.
4-1
Cisco MDS 9000 Family Troubleshooting Guide
OL-5183-02, Cisco MDS SAN-OS Release 1.3
4
Troubleshooting Switch Fabric Level Issues
This chapter describes switch fabric-level troubleshooting procedures and includes the following
sections:
• Troubleshooting Name Server Issues, page 4-1
• Troubleshooting FSPF Issues, page 4-6
• Troubleshooting Zoning Issues, page 4-14
Troubleshooting Name Server Issues
This section describes how to identify and resolve problems with the Cisco MDS 9000 Family name
server. It includes the following sections:
• Overview, page 4-1
• Nx Port Registration Problems, page 4-2
Overview
The name server provides a way for N ports and NL ports to register and discover FibreChannel
attributes. Registrations may happen explicitly, as a consequence of a request of the Nx port, or
implicitly by the switch at FLOGI time. Once registered, the attributes are made available to other Nx
ports or other switches. A separate name server database is maintained for each VSAN. The name server
uses the Fibre Channel Common Transport protocol (FC-CT) to communicate with Nx ports and
represents itself as an N port at the well-known FCID 0xFFFFFC.
One instance of the name server process runs on each Cisco MDS 9000 Family switch. In a multi-switch
fabric configuration, instances running on different switches share information and create a distributed
database of Nx port attributes. The name server defines a set of attribute objects with the following
operations on those objects:
• Register Object
• Deregister Object
• Get Object
To troubleshoot name server problems, check the status of these three operations and verify the correct
distribution of attributes among name server instances within the fabric. These attributes include the
following:
• Port Type
