Send comments to mdsfeedback-doc@cisco.com.
1-9
Cisco MDS 9000 Family Troubleshooting Guide
OL-5183-02, Cisco MDS SAN-OS Release 1.3
Chapter 1 Troubleshooting Overview
Using Cisco MDS 9000 Family Tools
2000000c306c2440(0xfffceb) -->idem, but looped around
Latency 0 msec
2000000c30575ec0(0xfffced) --> first hop MDS on the return path from traced FCID to
originor
switch#
Cisco Fabric Manager
Cisco Fabric Manager provides fabric-wide management capabilities including discovery, multiple
switch configuration, network monitoring, and troubleshooting. It provides the troubleshooting features
described in the following topics:
• Fabric Manager and Device Manager, page 1-9
• Analyzing Switch Device Health, page 1-10
• Analyzing End-to-End Connectivity, page 1-11
• Analyzing Switch Fabric Configuration, page 1-11
• Analyzing the Results of Merging Zones, page 1-12
• Alerts and Alarms, page 1-13
Note For detailed information about using Cisco Fabric Manager, refer to the Cisco MDS 9000 Family Fabric
Manager User Guide.
Fabric Manager and Device Manager
Fabric Manager provides a map of the discovered fabric and includes tables that display statistical
information about the switches in the fabric. You can also select troubleshooting tools from the Fabric
Manager Tools menu.
Note When you click on a zone or VSAN in Fabric Manager, the members of the zone or VSAN are
highlighted on the Fabric Manager Map pane.
Device Manager provides a graphic display of a specific switch and shows the status of each port on the
switch. From Device Manager, you can drill down to get detailed statistics about a specific switch or
port.
Figure 1-1 shows the Device Manager Summary View window.
