Cisco MDS 9000 Family Troubleshooting Guide
OL-5183-02, Cisco MDS SAN-OS Release 1.3
Chapter 1 Troubleshooting Overview
Using Cisco MDS 9000 Family Tools
FC Ping and FC Traceroute
Note FC Ping and FC traceroute are used to troubleshoot problems with connectivity and path choices. They
are not designed for use in identifying or resolving performance issues.
Ping and Traceroute are two of the most useful tools for troubleshooting TCP/IP networking problems.
The Ping utility generates a series of echo packets to a destination across a TCP/IP internetwork. When
the echo packets arrive at the destination, they are re-routed and sent back to the source. Using Ping, you
can verify connectivity and latency to a particular destination across an IP routed network. Traceroute
operates in a similar fashion, but can also determine the specific path that a frame takes to its destination
on a hop-by-hop basis. These tools have been migrated to Fibre Channel for use with the Cisco MDS
9000 Family switches and are called FC Ping and FC Traceroute. You can use FC Ping and FC
Traceroute from the CLI or from the Cisco Fabric Manager.
FC Ping allows you to ping a Fibre Channel N_Port or end device. By specifying the FC_ID or Fibre
Channel address, you can send a series of frames to a target N_Port. Once these frames reach the target
device’s N_Port, they are looped back to the source and a time-stamp is taken. FC Ping helps you to
verify the connectivity and latency to an end N_Port. FC Ping uses the PRLI Extended Link Service, and
verifies the presence of a FC entity in case of positive or negative answers.
qos Configure QOS Manager Debugging
rdl Configure RDL debugging
rib Configure rib debugging
rscn Configure RSCN debugging
scsi-target Configure scsi target daemon debugging
security Configure debugging for security/accounting
sensor Enable Sensor Mgr debugging
span Configure SPAN debug
system Enable System debugging
tlport Configure TL Port debugging
vni Enable virtual network interface debugging
vrrp Enable vrrp debugging
vsan Enable VSAN manager debugging
vsh Enable vsh debugging
vshd Configure vshd debugging
wwn Configure WWN Manager Debugging
xbar Enable xbar debugging
xbc Enable Xbar Client debugging
zone Zone server debug commands
Table 1-1 Debug commands (continued)
Debug command Purpose

Cisco MDS 9000 Series Specifications

General

Category	Switch
Operating System	Cisco NX-OS
Ports	Varies by model
Protocols	Fibre Channel (FC), Fibre Channel over IP (FCIP), iSCSI
Redundancy	Redundant supervisors, power supplies, and fans
Management	Cisco Data Center Network Manager (DCNM), CLI, SNMP
Virtualization Support	VSANs (Virtual SANs)
Security Features	Fibre Channel Security Protocol (FC-SP)
Hot Swappable Components	power supplies, fans
Power Supply Options	AC and DC options available
