Figure 8: Standard Hardware Features on the Front and Sides of the Cisco Nexus 7018 Chassis
Air intake for power supply units5System status LEDs1
Air intake for the supervisor modules and I/O
modules
6Rack-mount brackets (2)2
Air intake for fabric modules7I/O or NAM modules (1 to 16 in slots 1 to 8 and
slots 11 to 18).
3
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
16
Overview
Cisco Nexus 7018 System
