Bandwidth Management
Creation of New Bandwidth Management Rules
Cisco Small Business RV0xx Series Routers Administration Guide 188
F
e. In the
Max. Rate
field, enter the maximum rate for the maximum bandwidth. For
example, you can set a maximum rate of 80 kbit/sec.
f. Select Enable to enable this rule.
g. After you have set up the rule, click Add to list.
STEP 3 Set up an upstream rule for Vonage 2.
a. Select Vonage 2 from the
Service
drop-down menu.
b. Enter the IP address or range you need to control. To include all internal IP
addresses, keep the default, 0.
c. From the
Direction
drop-down menu, select Upstream for outbound traffic.
d. In the
Min. Rate
field, enter the minimum rate for the guaranteed bandwidth. For
example, you can set a minimum rate of 40 kbit/sec.
e. In the
Max. Rate
field, enter the maximum rate for the maximum bandwidth. For
example, you can set a maximum rate of 80 kbit/sec.
f. Select Enable to enable this rule.
g. After you have set up the rule, click Add to list.
STEP 4 Set up a downstream rule for Vonage 2.
a. Select Vonage 2 from the
Service
drop-down menu.
b. Enter the IP address or range you need to control. To include all internal IP
addresses, keep the default, 0.
c. From the
Direction
drop-down menu, select Downstream for inbound traffic.
d. In the
Min. Rate
field, enter the minimum rate for the guaranteed bandwidth. For
example, you can set a minimum rate of 40 kbit/sec.
e. In the
Max. Rate
field, enter the maximum rate for the maximum bandwidth. For
example, you can set a maximum rate of 80 kbit/sec.
f. Select Enable to enable this rule.
g. After you have set up the rule, click Add to list.
STEP 5 Click Save.
