Cisco RV082 - Small Business VPN Router User Manual

VPN
Introduction to VPNs
Cisco Small Business RV0xx Series Routers Administration Guide 123
9
Site to Site VPN (Gateway To Gateway)
In a site-to-site or gateway-to-gateway VPN, a VPN router at one office connects
to a VPN router at a remotely located office. Client devices can access network
resources as if they were all at the same site. This model can be used for multiple
users at a remote office.
In the following example, the main office (Site A) and a remote office (Site B) are
connected by a VPN tunnel. Users at both sites have access to the network
resources at both sites.
Configuration tasks:
Use the VPN > Gateway to Gateway page to configure the VPN tunnel. For
instructions, see Setting Up a Gateway to Gateway (Site to Site) VPN,
page 130. For more details and examples, see Appendix D, “Configuring a
Gateway-to-Gateway VPN Tunnel Between RV0xx Series Routers.”
Remote Access (Client To Gateway)
In a remote access or client-to-gateway VPN, a computer with VPN client software
connects to a VPN router. For this scenario, you can install third-party VPN client
software on the users’ computers. Alternatively, a VPN tunnel can be accessed
from any computer with the built-in IPSec Security Manager (Windows 2000,
Windows XP, and Windows 7).
1
99468
Site A
RV016
router
RV042
router
Site B
Inside
192.168.1.1/24
Outside
209.165.200.226/24
Outside
209.165.200.236/24
Inside
192.168.2.1/24
Personal
computers
Personal
computers
Printer Printer
Internet

Cisco RV082 - Small Business VPN Router Specifications

General

VPN Tunnels	50
DHCP Server	Yes
Authentication	MD5, SHA1
Power Supply	12V DC, 1A
Humidity	10% to 85% non-condensing
LAN Ports	8 x 10/100 Mbps RJ-45
VPN Protocols	IPSec, PPTP, L2TP
Firewall	SPI
Encryption	DES, 3DES, AES
Memory	8 MB Flash, 32 MB DRAM
Operating Temperature	0 to 40°C
Storage Temperature	-4 to 158°F (-20 to 70°C)
Weight	0.69 kg
