VPN
Setting Up a Gateway to Gateway (Site to Site) VPN
Cisco Small Business RV0xx Series Routers Administration Guide 130
9
Setting Up a Gateway to Gateway (Site to Site) VPN
Use the VPN > Gateway to Gateway page to create a new tunnel between two
VPN devices, such as a Cisco RV082 router at your office and a Cisco RV042
router at a remote office.
You will enter the settings for the local group and the remote group, and you will
enter the corresponding settings (reversing “local” and “remote”) when configuring
the other router. A successful connection requires that at least one router is
identifiable by a static IP address or a Dynamic DNS hostname. Alternatively, if one
router has only a dynamic IP address, you can use any email address as
authentication to establish the connection.
NOTE The two ends of the tunnel cannot be on the same subnet. For example, if the Site A
LAN uses the 192.168.1.x subnet, Site B could use 192.168.2.x.
You will enter corresponding settings (reversing “local” and “remote”) when
configuring the two routers. When you configure this router (Router A), enter its
settings in the Local Group Setup section, and enter the settings for the other
router (Router B) in the Remote Group Setup section. When you configure the
other router (Router B), enter its settings in the Local Group Setup section, and
enter the Router A settings in the Remote Group Setup section. For more details
and examples, see Appendix D, “Configuring a Gateway-to-Gateway VPN
Tunnel Between RV0xx Series Routers.”.
To open this page: Click VPN > Gateway to Gateway in the navigation tree.
Alternatively, you can click the Add Tunnel button on the VPN > Summary page, in
the Tunnel Status section. Then choose Gateway to Gateway.
99468
Site A
RV016
router
RV042
router
Site B
Inside
192.168.1.1/24
Outside
209.165.200.226/24
Outside
209.165.200.236/24
Inside
192.168.2.1/24
Personal
computers
Personal
computers
Printer Printer
Internet
