Cisco RV082 - Small Business VPN Router User Manual

Cisco Small Business RV0xx Series Routers Administration Guide 54
3
Editing the MAC Address Clone Settings
The Edit MAC Address Clone page appears after you click the Edit icon on the
MAC Address Clone page.
NOTE Before navigating away from this page, click Save to save your settings, or click
Cancel to undo them. Any unsaved changes are abandoned.
To clone a MAC address, enter the following settings.
• User Defined WAN MAC Address: To manually clone a MAC address, click
the radio button, and then enter the 12 digits of the MAC address that you
registered with your ISP.
• MAC Address from this PC: To clone the MAC address of the computer
you are currently using to configure the router, click this radio button. The
MAC address of your PC is displayed automatically.

Cisco RV082 - Small Business VPN Router Specifications

General

VPN Tunnels	50
DHCP Server	Yes
Authentication	MD5, SHA1
Power Supply	12V DC, 1A
Humidity	10% to 85% non-condensing
LAN Ports	8 x 10/100 Mbps RJ-45
VPN Protocols	IPSec, PPTP, L2TP
Firewall	SPI
Encryption	DES, 3DES, AES
Memory	8 MB Flash, 32 MB DRAM
Operating Temperature	0 to 40°C
Storage Temperature	-4 to 158°F (-20 to 70°C)
Weight	0.69 kg
