Cisco RV320 User Manual

Log
System Statistics
110 Cisco RV320/RV325 Administration Guide
10
Additional Information (Log Buttons)
If the web browser displays a warning about the pop-up window, allow the
blocked content. Click Refresh to update the data.
Click the following buttons to view additional information:
• View System Log—View the System Log. To specify a log, select the filter
from the drop-down menu.
Log entries include the date and time of the event, the event type, and a
message.The message specifies the type of policy, such as Access Rule,
the LAN IP address of the source (SRC), and the MAC address.
• Outgoing Log Table—Outgoing packet information.
• Incoming Log Table—Incoming packet information.
• Clear Log Now—Click to clear the log without emailing it, only if you do not
want to view the information in the future.
System Statistics
Detailed information about the ports and the devices attached to them are shown.
Processes
Detailed information about the running processes is shown.

Cisco RV320 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB version	2.0
USB ports quantity	2
Ethernet LAN (RJ-45) ports	6
Gigabit Ethernet (copper) ports quantity	4
Routing protocols	RIP-1, RIP-2
Supported network protocols	IPv4, IPv6, Static IP, PPPoE, PPTP, DNS, DynDNS
VPN support	IPsec, L2TP, DPD, DNS
Firewall security	Port Address Translation (PAT) firewall, Stateful packet inspection (SPI) firewall, Network address translation (NAT) firewall
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES, HTTPS, MD5, SHA-1, SSL/TLS
VPN tunnels quantity	25
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC, CE, UL, cUL, CB, CCC, BSMI, KC, Anatel
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No
LED indicators	Activity, LAN, Link, Power, USB, WAN
Input current	1.5 A
Output voltage	12 V

Weight and Dimensions

Depth	44 mm
Width	206 mm
Height	132 mm
Weight	- g
