DHCP
Viewing the DHCP Status
48 Cisco RV320/RV325 Administration Guide
4
• DHCP Relay—Passes DHCP requests and replies from another DHCP
server through the device.
• Client Lease Time—Amount of time that a network user is allowed to
connect to the router with the current IP address. Enter the amount of time in
minutes. Valid values are 5 to 43200 minutes. The default is 1440 minutes
(equal to 24 hours).
• DNS Server 1 and DNS Server 2—(Optional) IP address of a DNS server. If
you enter a second DNS server, the device uses the first DNS server to
respond. Specifying a DNS server can provide faster access than using a
DNS server that is dynamically assigned. Use the default setting of 0.0.0.0 to
use a dynamically assigned DNS server.
STEP 4 Enter the IPv6 address pool:
• Start Address—Beginning address of the IPv6 address pool.
• End Address—Ending address of the IPv6 address pool.
• Prefix Length—Length of the IPv6 IP address prefix.
Viewing the DHCP Status
DHCP Status displays the status of the DHCP server and its clients.
The IPv6 tab is available only if you enabled Dual-Stack IP on the Setup Network
page.
To view DHCP status and clients, click the IPv4 tab or the IPv6 tab. For IPv4, select
VLAN or Option 82. For IPv6, select the Prefix.
For the DHCP server, the following information is shown:
• DHCP Server—IP address of the DHCP server.
• Dynamic IP Used—Number of dynamic IP addresses used.
• Static IP Used (IPv4 only)—Number of static IP addresses used.
• DHCP Available—Number of dynamic IP addresses available.
• Total—Total number of dynamic IP addresses managed by the DHCP
server.

Cisco RV320 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB version	2.0
USB ports quantity	2
Ethernet LAN (RJ-45) ports	6
Gigabit Ethernet (copper) ports quantity	4
Routing protocols	RIP-1, RIP-2
Supported network protocols	IPv4, IPv6, Static IP, PPPoE, PPTP, DNS, DynDNS
VPN support	IPsec, L2TP, DPD, DNS
Firewall security	Port Address Translation (PAT) firewall, Stateful packet inspection (SPI) firewall, Network address translation (NAT) firewall
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES, HTTPS, MD5, SHA-1, SSL/TLS
VPN tunnels quantity	25
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC, CE, UL, cUL, CB, CCC, BSMI, KC, Anatel
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No
LED indicators	Activity, LAN, Link, Power, USB, WAN
Input current	1.5 A
Output voltage	12 V

Weight and Dimensions

Depth	44 mm
Width	206 mm
Height	132 mm
Weight	- g
