Cisco RV320 User Manual

Getting Started
Features of the User Interface
8 Cisco RV320/RV325 Administration Guide
1
Troubleshooting Tips
If you have trouble connecting to the Internet or the web-based web interface:
• Verify that your web browser is not set to Work Offline.
• Check the local area network connection settings for your Ethernet adapter.
The PC should obtain an IP address through DHCP. Alternatively, the PC can
have a static IP address in the 192.168.1.x range with the default gateway
set to 192.168.1.1 (the default IP address of the device).
• Verify that you entered the correct settings in the Wizard to set up your
Internet connection.
• Reset the modem and the device by powering off both devices. Next,
power on the modem and let it sit idle for about 2 minutes. Then power on
the device. You should now receive a WAN IP address.
• If you have a DSL modem, ask your ISP to put the DSL modem into bridge
mode.
Features of the User Interface
The user interface is designed to make it easy for you to set up and manage your
device.
Navigation
The major modules of the web interface are represented by buttons in the left
navigation pane. Click a button to view more options. Click an option to open a
page.
Pop-Up Windows
Some links and buttons launch pop-up windows that display more information or
related configuration pages. If your web browser displays a warning message
about the pop-up window, allow the blocked content.
Help
To view information about the selected configuration page, click Help near the top
right corner of the web interface. If your web browser displays a warning
message about the pop-up window, allow the blocked content.

Cisco RV320 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB version	2.0
USB ports quantity	2
Ethernet LAN (RJ-45) ports	6
Gigabit Ethernet (copper) ports quantity	4
Routing protocols	RIP-1, RIP-2
Supported network protocols	IPv4, IPv6, Static IP, PPPoE, PPTP, DNS, DynDNS
VPN support	IPsec, L2TP, DPD, DNS
Firewall security	Port Address Translation (PAT) firewall, Stateful packet inspection (SPI) firewall, Network address translation (NAT) firewall
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES, HTTPS, MD5, SHA-1, SSL/TLS
VPN tunnels quantity	25
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC, CE, UL, cUL, CB, CCC, BSMI, KC, Anatel
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No
LED indicators	Activity, LAN, Link, Power, USB, WAN
Input current	1.5 A
Output voltage	12 V

Weight and Dimensions

Depth	44 mm
Width	206 mm
Height	132 mm
Weight	- g
