VPN
Gateway to Gateway
84 Cisco RV320/RV325 Administration Guide
8
• Enable—Check this box to enable the VPN tunnel, or uncheck it to disable
the tunnel. By default, the tunnel is enabled.
Local Group Setup
Enter the settings for the Local Group Setup for this router. (Mirror these settings
when configuring the VPN tunnel on the other router. )
NOTE All the options are documented, but only those options that relate to the selected
parameter display.
Keying Mode = Manual or IKE with Preshared Key
• Local Security Gateway Type—Method for identifying the router to
establish the VPN tunnel. The Local Security Gateway is on this router; the
Remote Security Gateway is on the other router. At least one of the routers
must have either a static IP address or a DNS hostname to make a
connection.
- IP Only—This router has a static WAN IP address. The WAN IP address
appears automatically.
- IP + Certificate—This router has a static WAN IP address that appears
automatically. This option is only available when IKE with Certificate is
selected.
- IP + Domain Name (FQDN) Authentication—This device has a static IP
address and a registered domain name, such as
MyServer.MyDomain.com. Also enter the Domain Name to use for
authentication. The domain name can be used only for one tunnel
connection.
- IP + E-mail Addr.(USER FQDN) Authentication—This device has a
static IP address and an email address is used for authentication. The
WAN IP address appears automatically. Enter the Email Address to use
for authentication.
- Dynamic IP + Domain Name (FQDN) Authentication—This router has a
dynamic IP address and a registered Dynamic DNS hostname (available
from providers such as DynDNS.com). Enter a Domain Name to use for
authentication. The domain name can be used only for one tunnel
connection.

Cisco RV320 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB version	2.0
USB ports quantity	2
Ethernet LAN (RJ-45) ports	6
Gigabit Ethernet (copper) ports quantity	4
Routing protocols	RIP-1, RIP-2
Supported network protocols	IPv4, IPv6, Static IP, PPPoE, PPTP, DNS, DynDNS
VPN support	IPsec, L2TP, DPD, DNS
Firewall security	Port Address Translation (PAT) firewall, Stateful packet inspection (SPI) firewall, Network address translation (NAT) firewall
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES, HTTPS, MD5, SHA-1, SSL/TLS
VPN tunnels quantity	25
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC, CE, UL, cUL, CB, CCC, BSMI, KC, Anatel
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No
LED indicators	Activity, LAN, Link, Power, USB, WAN
Input current	1.5 A
Output voltage	12 V

Weight and Dimensions

Depth	44 mm
Width	206 mm
Height	132 mm
Weight	- g
