Cisco RV320 User Manual

VPN
Gateway to Gateway
Cisco RV320/RV325 Administration Guide 85
8
- Dynamic IP + E-mail Addr.(USER FQDN) Authentication—This router
has a dynamic IP address and does not have a Dynamic DNS hostname.
Enter an Email Address to use for authentication.
If both routers have dynamic IP addresses (as with PPPoE connections),
do not choose Dynamic IP + Email Addr. for both gateways. For the
remote gateway, choose IP Address and IP Address by DNS Resolved.
Keying Mode = IKE with Certificate
• Local Security Gateway Type—LAN resources that can use this tunnel.
The only option is IP + Certificate.
- IP Address—Displays the WAN IP address of the device.
• Local Certificate—Certificates available in the Certificate Management >
My Certificate window. Select the certificate from the drop-down menu.
Self-Generator displays the Certificate Generator window.
Import Certificate displays the My Certificate window.
• Local Security Group Type—Allows selection of a single IP address, a
Subnet, or an IP (address) Range within a subnet.
- IP Address—Specify one device that can use this tunnel. Enter the IP
Address of the device.
- Subnet—Allow all devices on a subnet to use the VPN tunnel. Enter the
subnetwork IP Address and Subnet Mask.
- Begin IP and End IP (IP Range)—A range of devices that can use the
VPN tunnel. Enter the first IP address in Begin IP and the end IP address
in End IP.

Cisco RV320 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB version	2.0
USB ports quantity	2
Ethernet LAN (RJ-45) ports	6
Gigabit Ethernet (copper) ports quantity	4
Routing protocols	RIP-1, RIP-2
Supported network protocols	IPv4, IPv6, Static IP, PPPoE, PPTP, DNS, DynDNS
VPN support	IPsec, L2TP, DPD, DNS
Firewall security	Port Address Translation (PAT) firewall, Stateful packet inspection (SPI) firewall, Network address translation (NAT) firewall
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES, HTTPS, MD5, SHA-1, SSL/TLS
VPN tunnels quantity	25
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC, CE, UL, cUL, CB, CCC, BSMI, KC, Anatel
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No
LED indicators	Activity, LAN, Link, Power, USB, WAN
Input current	1.5 A
Output voltage	12 V

Weight and Dimensions

Depth	44 mm
Width	206 mm
Height	132 mm
Weight	- g
