Setup
MAC Address Cloning
Cisco RV320/RV325 Administration Guide 39
3
To enable this feature, check Enable.
To add an entry to the list, click Add and enter the following information:
• Private Range Begin—Starting IP address of the internal IP address range
that you want to map to the public range. Do not include the router
management IP address in this range.
• Public Range Begin—Starting IP address of the public IP address range
provided by the ISP. Do not include the router WAN IP address in this range.
• Range Length—Number of IP addresses in the range. The range length
cannot exceed the number of valid IP addresses. To map a single address,
enter 1.
To modify an entry, check the entry that you want to modify and click Edit. The
information appears in the text fields. Make the changes and click Save.
MAC Address Cloning
Some ISPs require that you register a MAC address (the unique 12-digit
identification code assigned to every network device). If you previously registered
a different MAC address for the device with your ISP, you can select this feature to
clone that address to your device. Otherwise, you must contact your ISP to
change the registered MAC address.
NOTE When MAC Address Clone is enabled, port mirroring does not work.
To clone a MAC address:
STEP 1 Click the Interface radio button.
STEP 2 Click Edit to display the Edit MAC Address Clone page.
• User Defined WAN MAC Address—Click the radio button and enter the 12
digits of the MAC address that you registered with your ISP.
• MAC Address from this PC—Click to use the MAC address of your
computer as the clone MAC address for the device.
STEP 3 Click Save.

Cisco RV320 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB version	2.0
USB ports quantity	2
Ethernet LAN (RJ-45) ports	6
Gigabit Ethernet (copper) ports quantity	4
Routing protocols	RIP-1, RIP-2
Supported network protocols	IPv4, IPv6, Static IP, PPPoE, PPTP, DNS, DynDNS
VPN support	IPsec, L2TP, DPD, DNS
Firewall security	Port Address Translation (PAT) firewall, Stateful packet inspection (SPI) firewall, Network address translation (NAT) firewall
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES, HTTPS, MD5, SHA-1, SSL/TLS
VPN tunnels quantity	25
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC, CE, UL, cUL, CB, CCC, BSMI, KC, Anatel
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No
LED indicators	Activity, LAN, Link, Power, USB, WAN
Input current	1.5 A
Output voltage	12 V

Weight and Dimensions

Depth	44 mm
Width	206 mm
Height	132 mm
Weight	- g
