Firewall
Content Filter
Cisco RV320/RV325 Administration Guide 79
7
STEP 4 Click Save.
Accepting Allowed Domains
To specifically accept a domain:
STEP 1 Select Accept Allowed Domains.
STEP 2 Click Add (or Edit) in the Allowed Domains table.
STEP 3 Enter the name in the Domain Name column.
STEP 4 Click Save.
Scheduling
The restrictions can be scheduled for a specific time on selected days.
To schedule time and days:
STEP 1 Select the Time from the drop-down menu. Select Always for the rule to be in
effect 24 hours a day. Select Interval to set a time.
STEP 2 If you selected Always in STEP 1, skip to STEP 4. If you selected Interval, set a
time by entering the hours and minutes that the access rule is effective in the From
and To fields. For example, 07:00 to 20:00. Content filter does not allow setting
two time intervals.
STEP 3 Check the Effective On days of the week.
STEP 4 Click Save.

Table of Contents

Other manuals for Cisco RV320

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco RV320 and is the answer not in the manual?

Cisco RV320 Specifications

General IconGeneral
Ethernet LANYes
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.3, IEEE 802.3u
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet interface typeGigabit Ethernet
USB version2.0
USB ports quantity2
Ethernet LAN (RJ-45) ports6
Gigabit Ethernet (copper) ports quantity4
Routing protocolsRIP-1, RIP-2
Supported network protocolsIPv4, IPv6, Static IP, PPPoE, PPTP, DNS, DynDNS
VPN supportIPsec, L2TP, DPD, DNS
Firewall securityPort Address Translation (PAT) firewall, Stateful packet inspection (SPI) firewall, Network address translation (NAT) firewall
Security algorithms128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES, HTTPS, MD5, SHA-1, SSL/TLS
VPN tunnels quantity25
Authentication methodSHA-1, MD5
MAC address filtering-
CertificationFCC, CE, UL, cUL, CB, CCC, BSMI, KC, Anatel
Storage temperature (T-T)0 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 85 %
Product colorBlack
Rack mountingNo
LED indicatorsActivity, LAN, Link, Power, USB, WAN
Input current1.5 A
Output voltage12 V
Weight and Dimensions IconWeight and Dimensions
Depth44 mm
Width206 mm
Height132 mm
Weight- g
