Cisco SG220-26P Administration Guide

IP Configuration
Configuring Domain Name System
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 186
15
• Status— Displays the results of attempts to access the host (always shows
OK for static entries).
STEP 2 To add a host mapping, click Add.
STEP 3 Enter the following information:
• IP Version—Select either Version 6 or Version 4.
• Host Name—Enter a user-defined host name or fully-qualified name. Host
names are restricted to the ASCII letters A through Z (case-insensitive), the
digits 0 through 9, the underscore and the hyphen. A period (.) is used to
separate labels.
• IP Address (es)—Enter a single address or up to eight associated IP
addresses (IPv4 or IPv6).
STEP 4 Click Apply. The host mapping is added, and the Running Configuration is
updated.

Cisco SG220-26P Specifications

General

Model	SG220-26P
Ports	26
PoE Ports	24
Switching Capacity	52 Gbps
Forwarding Rate	38.69 Mpps
Layer	Layer 2
Power Supply	Internal
VLANs Supported	256
Management	Web-based GUI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-4°F to 158°F (-20°C to 70°C)
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Dimensions	440 x 44 x 257 mm
Weight	3.3 kg
