Cisco SG220-26P Administration Guide

Administration: File Management
Copy/Save Configuration Files
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 53
4
!
CAUTION Unless the Running Configuration is copied to the Startup Configuration or another
configuration file, all changes made since the last time the file was copied are lost
when the switch is rebooted.
The following combinations of copying internal file types are allowed:
• From the Running Configuration to the Running Configuration, Startup
Configuration or Backup Configuration.
• From the Startup Configuration to the Running Configuration, Startup
Configuration, or Backup Configuration.
• From the Backup Configuration to the Running Configuration, Startup
Configuration, or Backup Configuration.
• From the Mirror Configuration to the Running Configuration, Startup
Configuration, or Backup Configuration.
To copy one type of configuration file to another type of configuration file:
STEP 1 Click Administration > File Management > Copy/Save Configuration.
STEP 2 Enter the following information:
• Source File Name—Select the configuration file type to be copied.
• Destination File Name—Select the configuration file type to be overwritten
by the source file.
STEP 3 Click Apply. The file is copied and the switch is updated.
STEP 4 The Save Icon Blinking field indicates whether an icon blinks when there is
unsaved data. To disable or enable this feature, click Disable Save Icon Blinking
or Enable Save Icon Blinking.

Cisco SG220-26P Specifications

General

Model	SG220-26P
Ports	26
PoE Ports	24
Switching Capacity	52 Gbps
Forwarding Rate	38.69 Mpps
Layer	Layer 2
Power Supply	Internal
VLANs Supported	256
Management	Web-based GUI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-4°F to 158°F (-20°C to 70°C)
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Dimensions	440 x 44 x 257 mm
Weight	3.3 kg
