xConfiguration H323 H323Alias E164
The H.323 Alias E.164 defines the address of the system, according to the numbering plan
implemented in the H.323 Gatekeeper. The E.164 alias is equivalent to a telephone number,
sometimes combined with access codes.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration H323 H323Alias E164: "E164 "
where
E164 : String (0, 30)
The H.323 Alias E.164 address. Valid characters are 0-9, * and #.
xConfiguration H323 H323Alias ID
Define the H.323 Alias ID, which is used to address the system on a H.323 Gatekeeper and will
be displayed in the call lists.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration H323 H323Alias ID: "ID"
where
ID : String (0, 49)
The H.323 Alias ID. Example: "firstname.lastname@company.com", "My H.323 Alias ID"
xConfiguration H323 NAT Mode
The firewall traversal technology creates a secure path through the firewall barrier, and enables
proper exchange of audio/video data when connected to an external video conferencing
system (when the IP traffic goes through a NAT router). NOTE: NAT does not work in conjunc-
tion with gatekeepers.
Requires user role: ADMIN
Default value: Off
USAGE:
xConfiguration H323 NAT Mode: Mode
where
Mode : Auto/Off/On
Auto: The system will determine if the H323 NAT Address or the real IP address should
be used in signaling. This makes it possible to place calls to endpoints on the LAN as
well as endpoints on the WAN. If the H323 NAT Address is wrong or not set, the real IP
address will be used.
Off: The system will signal the real IP address.
On: The system will signal the configured H323 NAT Address instead of its real IP
address in Q.931 and H.245. The NAT server address will be shown in the startup-
menu as: "My IP Address: 10.0.2.1". If the H323 NAT Address is wrong or not set, H.323
calls cannot be set up.
