Chapter 2 Catalyst 3560 Switch Cisco IOS Commands
auto qos voip
Table 2-2 shows the generated auto-QoS configuration for the ingress queues.
Table 2-3 shows the generated auto-QoS configuration for the egress queues.
Command Modes Interface configuration
Command History
Usage Guidelines Use this command to configure the QoS appropriate for VoIP traffic within the QoS domain. The QoS
domain includes the switch, the interior of the network, and edge devices that can classify incoming
traffic for QoS.
In releases earlier than Cisco IOS Release 12.2(20)SE, auto-QoS configures the switch only for VoIP
with Cisco IP Phones on switch ports.
In Cisco IOS Release 12.2(20)SE or later, auto-QoS configures the switch for VoIP with Cisco IP Phones
on switch and routed ports and for VoIP with devices running the Cisco SoftPhone application. These
releases support only Cisco IP SoftPhone Version 1.3(3) or later. Connected devices must use Cisco Call
Manager Version 4 or later.
To take advantage of the auto-QoS defaults, you should enable auto-QoS before you configure other QoS
commands. You can fine-tune the auto-QoS configuration after you enable auto-QoS.
Table 2-2 Auto-QoS Configuration for the Ingress Queues
Ingress Queue Queue Number CoS-to-Queue Map
Queue Weight
(Bandwidth)
Queue (Buffer)
Size
SRR
1
shared
1. SRR = shaped round robin. Ingress queues support shared mode only.
1 0, 1 81 percent 67 percent
Priority 2 2, 3, 4, 5, 6, 7 19 percent 33 percent
Table 2-3 Auto-QoS Configuration for the Egress Queues
Egress Queue Queue Number CoS-to-Queue Map
Queue Weight
(Bandwidth)
Queue (Buffer) Size
for Gigabit-Capable
Ports
Queue (Buffer)
Size for 10/100
Ethernet Ports
Priority (shaped) 1 5 10 percent 16 percent 10 percent
SRR shared 2 3, 6, 7 10 percent 6 percent 10 percent
SRR shared 3 2, 4 60 percent 17 percent 26 percent
SRR shared 4 0, 1 20 percent 61 percent 54 percent
Release Modification
12.1(19)EA1 This command was introduced.
12.2(20)SE The cisco-softphone keyword was added, and the generated auto-QoS
configuration changed.
